Sikafloor® Level-30

High performance, self levelling and fast drying, cementitious screed for interior or exterior in 4–30 mm

Sikafloor® Level-30 is a polymer modified, pumpable, self levelling fast drying cementitious screed for higher thickness interior or exterior floors, meeting the requirements of class R3 according to EN 1504-3.

Self smoothing and highly fluid
Easy to place by pump or manual application
Ready for use.
Low shrinkage.
Maintains good workability and joint healing throughout its pot life
Fast setting and drying
3–4 hours walk on time (+20 °C)
Good surface appearance and hardness
Excellent freeze-thaw salt resistance (R3)
Casein and Formaldehyde free
Suitable for use with under floor heating systems

Product Data Sheet Safety Data Sheet Show all documents

Usage

Sikafloor® Level-30 is an floor self levelling screed to level or smooth screeds and concrete floors at a thickness between 4–30mm in one working step.
Sikafloor® Level-30 is useable as screed for industrial service conditions when sealed with a PU or EP resin top coat from medium to high load (heavy-traffic + forklift pallet truck with impact load). Sikafloor® Level-30 is also suitable for filling, smoothing and levelling of suitable substrates before applying parquet, ceramic tiles, seamless resinfloors, textile , elastic floor coverings. Sikafloor® Level-30 is useable as screed for exterior areas when sealed with a covering, e.g. a coating.

Suitable for restoration work (Principle 3, method 3.1 of EN 1504-9).
Suitable for structural strengthening (principle 4, method 4.4 of EN 1504-9).
Suitable for preserving or restoring passivity (Principle 7, method 7.1 and 7.2 of EN 1504-9).

Advantages

Self smoothing and highly fluid
Easy to place by pump or manual application
Ready for use.
Low shrinkage.
Maintains good workability and joint healing throughout its pot life
Fast setting and drying
3–4 hours walk on time (+20 °C)
Good surface appearance and hardness
Excellent freeze-thaw salt resistance (R3)
Casein and Formaldehyde free
Suitable for use with under floor heating systems

Packaging

20 kg bags

Colour

Powder - beige-grey

Product Details

Sustainability / Certifications / Approvals

ENVIRONMENTAL INFORMATION

EC 1plus R: Very low emissions.

APPROVALS / STANDARDS

Cement based screed CT-C40-F10-A12 according to EN 13813, declaration of performance 90432755, and provided with CE marking
Cement based screed A1/A1fl according to EN 13813, declaration of performance 90432755, assessed by notified laboratory 1140, and provided with CE marking
Cement based screed class R3 for the principles 3 (CR), 4 (SS) and 7 (RP) according to EN 1504-3, declaration of performance 36581792, assessed by notified laboratory 1139, and provided with CE marking

Product Information

Chemical Base

Polymer modified rapid hardening cement.

Shelf Life

9 months from date of production

Storage Conditions

Store in original, unopened and undamaged packaging in dry conditions at temperatures between +5 °C and +30 °C.

Density

~2.0 kg/l

Bulk Density

~1.25 kg/l

System information

System Structure

Priming

See substrate pre-treatment

Levelling

Apply to the required thickness 4–30 mm

Sealer and coatings

Sikafloor^®-2540 W

All kinds Sikafloor^® EP & PU coatings

SikaCeram^® product range for the tile adhesives

Technical Information

Abrasion Resistance

Class

Value

Method

A12

12 cm³ / 50 cm²

Böhme

AR 0.5

< 50 μm

BCA

RWA 100

< 100 cm³

RWA

Compressive Strength

Time	Temperature	Value
24 hours	20 °C	~ 20 MPa
28 days	20 °C	≥ 40 MPa

Flexural Strength

Time	Temperature	Value
24 hours	20 °C	~ 3 MPa
28 days	20 °C	≥ 10 MPa

Tensile Adhesion Strength

Time	Temperature	Value
28 days	+20 °C	≥ 1.5 MPa

Coefficient of Thermal Expansion

α ~16.3×10^-6 1/°C

(for temperature range -20 °C and +40 °C)

(EN 1770)

Water Absorption

W ~0.5 kg / (m² × h^0.5 )

(EN 13057)

Application

Application Information

Mixing Ratio

4 - 4.2 litres of water for 20 kg Sikafloor® Level-30

Layer Thickness

4–30 mm

Ambient Air Temperature

+10 °C min. / +25 °C max.

Relative Air Humidity

< 75 %

Substrate Temperature

+10 °C min. / +25 °C max.

Pot Life

Temperature and

Relative Air Humidity

Time

+23 °C / 50%

~ 25 minutes

The temperature will affect the pot life.
Application at temperatures above +23 °C will reduce the pot life and the working time. Temperatures below +23 °C will increase the pot life and extend the working time.

Waiting Time / Overcoating

Covering	Layer Thickness	Waiting time
Impermeable or moisture sensitive coatings	≤ 15 mm	24 hours¹
Impermeable or moisture sensitive coatings	≤ 30 mm	48 hours¹
Ceramic covering	≤ 30 mm	~24 hours

Times are approximate and at +23 °C and 50% r.h. and thus will be affected by changing substrate and ambient conditions, particularly the temperature and relative humidity.

When overcoating Sikafloor® Level-30 always ensure the moisture content has achieved the required value for the coating product, as the waiting time will vary with the application thickness and ambient humidity. (Refer to the coating product data sheet)

Applied Product Ready for Use

At +20 °C and 50% r.h.

Foot traffic	~ 3 hours
Lightly serviceable	~ 24 hours

Note: Times are approximate and will be affected by changing substrate and ambient conditions, particularly the temperature and relative humidity.

Consumption

~1.8 kg/m²/mm

Application steps

MIXING

Manual Application

When mixing manually add the dry powder (25 kg) into a container with the clean water.
Mix thoroughly for a minimum of 3 minutes, by use of an electric stirrer, recommended is the use of a double disc stirring paddle or a spiral mix paddle (< 500 rpm).

Maturing time: After mixing leave the material to stand in the container for ~2 minutes until the majority of air bubbles have dispersed.

Pumping

When using a mortar pump with appropriate equipment (Putzmeister MP 20/25, DuoMix 2000 or PFT G5 FE) set the machine in a way that a uniform mixture is achieved. The use of a remixer is recommended.

Control the water dosage to achieve the required flow, measuring the final average flow diameter on a flat, clean, dry flow table.

Tool

Flow

Standard

Ø = 30 mm

H = 50 mm

130 mm

± 5 mm

EN 12706

Ø 70 / 100 mm

H = 60 mm

355 mm

± 10 mm

ASTM C 230-90

EN1015-3

Ø = 60 mm

H = 120 mm

290 mm

± 10 mm

Sika AT method

APPLICATION

Pour the mixed material onto the primed surface and apply by trowel or pin screed rake to the required thickness. Roll thoroughly with a spiked roller in two directions to remove any entrapped air. Best application time would be during falling temperatures.
