Sika® PEF Rod

Sika® PEF Rod

Backing rods for jointing requirements

Sika® PEF Rod is manufactured from the highest quality closed cell polyethylene to produce a joint backing material primarily for use in conjunction with elastomeric sealants.

  • Weather resistant
  • No water absorption, closed cell
  • No adhesion to sealants, sealant has unrestricted movement
  • Approved for use in food areas (Australia Standard AS2170)
  • Easy to install
  • Wide range of sizes available
  • Non toxic, odourless
  • Resistant to most chemicals
  • Easily compressible, good expansion
  • Very light weight
Product Data Sheet Show all documents

Usage

Sika® PEF Rod is pushed into joint gaps to form a uniform and firm base for controlling the depth of gun applied elastomeric sealants such as Sikaflex. Sika® PEF Rod can be used for forming the base of vertical and horizontal joints in the following applications:
  • Joints between precast concrete panels
  • Saw cut joints in concrete floors
  • Peripheral joints around aluminium and timber windows
  • Around penetrations through walls and floors
  • Expansion joints between bricks and masonry
  • Can also be used for draught-proofing and dust-proofing of joints in situations where no other form of sealing is required


Advantages

  • Weather resistant
  • No water absorption, closed cell
  • No adhesion to sealants, sealant has unrestricted movement
  • Approved for use in food areas (Australia Standard AS2170)
  • Easy to install
  • Wide range of sizes available
  • Non toxic, odourless
  • Resistant to most chemicals
  • Easily compressible, good expansion
  • Very light weight

Packaging

Sika® PEF Rod is available in the following sizes and lengths:

Diameter

Length per Roll

6 mm
8 mm
10 mm
12 mm
15 mm
20 mm
25 mm
30 mm
40 mm
50 mm

20 m & 250 m
20 m, 50 m & 250 m
20 m, 50 m & 250 m
20 m, 50 m & 150 m
20 m, 50 m & 100 m
20 m & 60 m
25 m
25 m
2 m length
2 m length

Colour

White

Product Details

Product Information

Chemical Base

Closed cell polyethylene foam.

Shelf Life

Indefinate

Storage Conditions

Store in original, unopened packaging in cool, dry conditions.

Density

37 kg/m³
Technical Information

Chemical Resistance

Unaffected by oils, petrol, sewage and most industrial chemicals

Thermal Conductivity

0.035 W/m.k.

Service Temperature

-40°C to +70°C
